Pasadena Water and Power | Arc Flash Studies for GT-1, GT-2, GT-3, GT-4, and GT-5 (Glenarm)

Owner: Pasadena Water and Power (PWP)
Period: 2024

Kewo Engineering developed arc flash reports for GT-1 & GT-2, GT-3 & GT-4, and GT-5 electrical systems. The arc flash assessment covers 200+ pieces of electrical equipment including 208V panelboards, 480V and 4.16kV switchgears, up to 13.8kV switchboards. This includes responsibilities as follows:

• Perform field verification, investigation and gather/collect all necessary data
• Review existing relay settings
• Review previous arc flash reports
• Develop Load Flow, Short Circuit, Relay Coordination, Arc Flash models using ETAP software
  • Update relay & equipment data
• Develop reports and Arc Flash warning labels
